Air core shielded inductor series
Shielded
Features
- Magnetic shielded
- High transient current spikes without saturation
- High saturation
- RoHS and REACH compliant
Applications
- High current Power supply devices
- Graphic cards
- Notebook and PCs
- Servers
All series
| Series ID | A | B | C | Inductance (UH) | DCR Max (mOhm) | Isat (A) Typ. | Irms (A) Typ. | Series spec |
|---|---|---|---|---|---|---|---|---|
| OWIPL0807 | 8.80 | 8.40 | 7.50 | 0.30 – 3.30 | 2.7 – 9.0 | 5 – 27 | 8 – 16 | |
| OWIPL1009 | 11.30 | 10.30 | 9.50 | 0.22 – 8.20 | 1.60 – 16.90 | 6 – 55 | 9 – 22 | |
| OWIPL1210 | 12.50 | 11.70 | 10.00 | 0.22 – 8.20 | 1.50 – 13.00 | 7 – 55 | 9 – 37 |
